Technical Specification
Feature Specification
Format Super 16 (12.35 × 7.42 mm)
Gate Native S16, supports standard 16 with GG
Shutter Reflex, 180°–144° adjustable
Frame Rates 3–75 fps (0.001 fps steps); presets
Lens Mount ARRI PL (std)
Magazine 2 x 400 ft (≈10 min @24fps each), quick-load
Power 10–14 V, ~600 mA; V-Mount compatible
Weight ~6 kg loaded
Viewfinder Bright reflex, multiple aspect ratios
Assist Color/BW video tap available
Noise ~20 dB
Temp Range –20 °C to +40 °C
Stability High, 1/2000 frame precision
